MAX 100W-200W Q-SWITCH PULSED FIBER LASER
Get Instant QuoteProduct Details
Q-Switch Pulsed Fiber Laser (MFP 100W-200W) Series are maintenance-free fiber lasers based on the Q-switch technology and MOPA. These lasers deliver light whose emission wavelength is centered at 1060nm and peak power is up to 10KW or above. The light is guided to the work piece via a flexible metal-sheathed fiber cable. The laser’s running parameters are set by the user’s special controller via a DB-25 interface.
| Models | MFP-100W | MFP-200W |
| OPTICAL SPECIFICATIONS | ||
| Nominal Power | 100W | 200W |
| Mode of Operation | Pulsed | |
| Polarization | Random | |
| Power Tunability | 5 to 100% | |
| Wavelength | 1064 ± 5 nm | |
| Power Stability | ≤5 % | |
| Laser Beam Quality M² | ≤2 @1.5 mJ | |
| Pulse Energy | 1.5~8 mJ | |
| Pulse Duration | 150~190 ns | 180~220 ns |
| Repetition Rate | 20~200 kHz | 30~200 kHz |
| Full Power Repetition Rate | 15 @6.7 mJ | 30 @6.7 mJ |
| FIBER DELIVERY SYSTEM | ||
| Length | 5m standard, other lengths optional | |
| Beam Diameter | 5~9 mm | |
| Beam Ellipticity | 90% | |
| ELECTRICAL RATINGS | ||
| Supply Voltage | 220 VAC Single-phase | |
| OTHER SPECIFICATIONS | ||
| Operating Temperature | +10 to +35℃ | |
| Storage Temperature | -10 to +60℃ | |
| Humidity | 10 to 95% | |
| Cooling Method | Air Cooling | |
| Dimension | 540.4×482.6×131.3 mm | |
| Weight | 21 kg | |
